Atle Harby is preserving a gas sample at Murum River in Malaysia. The gas sample are taken to the laboratory for analysis of methane and CO2 content to give information on natural greenhouse gas emissions before a new hydropower reservoir is created on the river. Photo: Julie Bastien

Reveals the real greenhouse gas footprints of reservoirs

When hydropower reservoirs traps organic matter, it leads to higher local greenhouse gas emissions. But the emissions are not increased but displaced. A new tool calculates the real greenhouse gas footprints of reservoirs.

Trees and plants absorb CO2 from the atmosphere to grow. When organic matter such as fallen leaves and branches degrades, CO2 is released back into the atmosphere. Water transports organic matter to the sea along rivers and along the way it might emit greenhouse gases such as CO2 and methane. Building a reservoir stops the flow of water and traps some of the organic matter.

“Greenhouse gases that are emitted in a reservoir may well have been emitted anyway. It is a displacement, not an increase, and this was not accounted for in earlier calculations. You must also consider the prior land use and the processes in the whole river basin,” says Atle Harby, a energy research scientist at SINTEF , who has been working on developing a tool, called G-res tool.

Reservoar emissions – a hot topic

The greenhouse gas status of freshwater reservoirs has been a hot topic over the past decade. Impacts are often attributed to hydropower projects, while a new framework and tool from the International Hydropower Association (IHA) shows that the truth is far more complex.

The net emissions approach considers naturally occurring emissions and emissions related to other human activities. The G-res tool enables users to estimate the real GHG footprint of reservoirs.

Hydropower adds no new carbon dioxide to the atmosphere

Almost twenty years ago, stories began to emerge in the media that reservoirs created for hydropower projects were a major emitter of greenhouse gases. Yet there were no actual measurements to back up the theories.

In 2006, the IPCC released their greenhouse gas guidelines that included three approaches with formulas to calculate emissions from reservoirs. Statkraft, Europe’s largest generator of renewable energy, used all three approaches to evaluate their measurements taken at the Trollheim reservoir and hydropower plant in central Norway.

The first approach using IPCC default values equated the emissions from Trollheim to those of a gas power plant. The second approach used some of their own data and halved the predicted emissions. Statkraft then engaged SINTEF to develop methodology and conduct measurements of emissions. The third approach using this data showed emissions from Trollheim would be around 2 g CO2eq/kWh, compared to 300 g CO2eq/kWh from a gas power plant.

“A hydropower reservoir does not add any new carbon dioxide to the atmosphere, unlike fossil-fuel power plants,” said Tormod Schei, who at the time worked as a Senior Environmental Advisor for Statkraft.

A surprising find in Laos

The Nam Ngum reservoir in Laos is characterised by a warm and humid climate with dense forest in the upstream catchment area. If the early claims were to be believed, the tropical conditions should have been ripe for high greenhouse gas emissions.

Yet a study from EDF and SINTEF published in the journal Science of the Total Environment in 2011 found that the 40-year-old Nam Ngum reservoir behaves as a carbon sink, with negative net greenhouse gas emissions because of low methane production and a high CO2 uptake by phytoplankton.

Schei calls the launch of the tool a major milestone in helping to assess the true value of hydropower.

“In Turkey, the Ataturk dam and reservoir is delivering on irrigation, while in China, flood control and transportation are more important than the energy produced. Understanding the likely greenhouse gas emissions of a new reservoir is a vital step in proper management of energy production and the river system,” he said.

The IPCC are now going to revise their guidelines for national greenhouse gas inventories with the help of Atle Harby and 15 other lead authors. The chapter on how to handle freshwater reservoirs (flooded land) will be revised following the new findings.
